Product Details:
|
| Product Name: | Column Type Load Cell | Capacity: | 5000N Or Customized |
|---|---|---|---|
| Non-linearity: | 0.01%F.S. Or Customized | Repeatability: | 0.01%F.S. Or Customized |
| Cable Size: | ⌀3x2000mm Or Customized | Material: | Alloy Steel Or Customized |
| High Light: | 5000n Column Type Load Cell,0.01% Column Type Load Cell,2m weight detection sensor |
||
5000N Or Customized Column Type Load Cell
1. Descriptions
5000N Or Customized Column Type Load Cell FA462 is a model of Column Type Load Cell, it can measure load 5000N or customized capacity, its Non-linearity and Repeatability are same 0.01%F.S. or customized, we could use Alloy Steel or other customized metallic material as its material.
2. Specifications
| Product name | Column Type Load Cell |
| Capacity | 5000N or customized |
| Rated output | 2.0±10%mV/V |
| Zero Balance | ±1%mV/V |
| Non-linearity | 0.01%F.S. or customized |
| Repeatability | 0.01%F.S. or customized |
| Recommended excitation | 5~12V |
| Maximum excitation | 15V |
| Compensated Temp Range | -10~60 ℃ |
| Operating Temp Range | -30~70 ℃ |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Cable size | ⌀3x2000mm or customized |
| Material | Alloy Steel or customized |
| IP Class | IP67 or customized |
3. Dimension
Need to be customized
4. Application
5000N Or Customized Column Type Load Cell is mainly suitable for electronic truck scales.
5.FAQ
Q1: What is your terms of delivery?
A: EXW, FOB, CFR and CIF.
Q2: Can you produce according to the samples?
A: Yes, we can produce according to your samples or technical drawings.
Q3:What is your sample policy?
A: We can supply the sample with discount if we have ready parts in stock, and customers pay the courier cost.
Q4: What's your quality guarantee policy?
A: Quality guarantee: 12 months.
If the product has quality problem within 12 months, please return it to us, we will repair it, if we can't repair it successfully, we will give you a new one; but the man-made damage, improper operation and force majeure will be excepted.
And you will pay the shipping cost of returning to us, we will pay the shipping cost of delivering to you.
Contact Person: Claire Li
Tel: +8618251209169
