Product Details:
|
| Product Name: | Load Cell Amplifier | Display Accuracy: | 0.001%F.S. |
|---|---|---|---|
| IP Class: | IP65 | Output Rate: | 10,40,80,120,200,400,600,800,1200,1600,2400,4800 Times/sec |
| Baud Rate: | 1200,2400,4800,9600,19200,38400,57600,115200,230400, 460800,921600 | Resolution: | 1/60000 |
| High Light: | 20ma strain gauge amplifier arduino,6 channel strain gauge amplifier arduino,ip65 lvdt amplifier |
||
Input Load 6 * 350Ω Sensors 0.001%F.S. IP65 Weight Sensor Instrument Load Cell Amplifier
1. Descriptions
Input Load 6 * 350Ω Sensors 0.001%F.S. IP65 Weight Sensor Instrument Load Cell Amplifier FA04C belongs to FA04 which is in Weight Sensor Instrument of our brand FIBOS Load Cell Amplifier category, FA04C has Dual-row 6-digit LED display and its Display accuracy is 1/100000, it allows up to 6 units of 350Ω sensors can be connected.
2. Specifications
| Product name | Load Cell Amplifier |
| Output specifications | 0.4~6mV/V |
| Display | Dual-row 6-digit LED display |
| Display accuracy | 1/100000 |
| Sensor excitation voltage | 5VDC±2%,100mA |
| Input load | Up to 6 units of 350Ω sensors can be connected |
| Power supply | DC:12V--30V |
| Operation temp range | -30~60℃ |
| IP Class | IP65 |
| A/D performance | 24-bit, Delta-Sigma method |
| Output rate | 10,40,80,120,200,400,600,800,1200,1600,2400,4800 Times/sec |
| Baud rate |
1200,2400,4800,9600,19200,38400,57600,115200,230400, 460800,921600 |
| Withstand voltage | 1 minute at 2000V AC50/60Hz |
| Surrounding environment |
Humidity:-10~55℃ Storage:-25~65℃ Humidity:35~85%RH Storage:35~85%RH |
| Protocol type | Modbus RTU, ASCII and Free Protocol |
| Communication output | RS232/RS485 |
| Analog output | 0~±10V,0~20mA,4~20mA |
| Resolution | 1/60000 |
3. Dimension
4. Application
Input Load 6 * 350Ω Sensors 0.001%F.S. IP65 Weight Sensor Instrument Load Cell Amplifier FA04C can be used to display values from force torque sensor.
5.FAQ
Q1: What is your terms of delivery?
A: EXW, FOB, CFR and CIF.
Q2: Can you produce according to the samples?
A: Yes, we can produce according to your samples or technical drawings.
Q3:What is your sample policy?
A: We can supply the sample with discount if we have ready parts in stock, and customers pay the courier cost.
Q4: What's your quality guarantee policy?
A: Quality guarantee: 12 months.
If the product has quality problem within 12 months, please return it to us, we will repair it, if we can't repair it successfully, we will give you a new one; but the man-made damage, improper operation and force majeure will be excepted.
And you will pay the shipping cost of returning to us, we will pay the shipping cost of delivering to you.
Contact Person: Eric
Tel: +8618136918991
