Product Details:
|
| Product Name: | Load Cell Amplifier | Display Accuracy: | ≤±0.05%F.S. |
|---|---|---|---|
| Sampling Frequency: | ≥5KHZ | IP Class: | IP64 |
| Operation Temp Range: | -30~85℃ | Power Supply: | DC:15~30V |
| High Light: | 24 bit Load Cell Amplifier,IP64 Load Cell Amplifier,5000hz strain gauge signal conditioner |
||
24-Bit IP64 ≥5KHZ 10,40,640,1280 Times/Sec Load Cell Amplifier
1. Descriptions
24-Bit IP64 ≥5KHZ 10,40,640,1280 Times/Sec Load Cell Amplifier FA01A-A4 is a model of our brand FIBOS Load Cell Amplifier and instrument series, weight transducer Load Cell Amplifier FA01A-A4 belongs to FA01 which is in instrument category, its Display accuracy ≤±0.05%F.S., its Rated output could be 0~5v,0~10v,0~±5v,0~±10v,0~20mA,0~20mA.
2. Specifications
| Product name | Load Cell Amplifier |
| Output specifications | 0.4~6mV/v |
| Display accuracy | ≤±0.05%F.S. |
| Sensor excitation voltage | 5VDC±2%,100mA(or 12VDC optional) |
| Power supply | DC:15~30V |
| A/D performance | 24-bit, Delta-Sigma method |
| Rated output |
0~5v,0~10v,0~±5v,0~±10v,0~20mA,0~20mA (All the above signals can be switched, no need to return to the factory) |
| Output rate | 10,40,640,1280 Times/sec |
| Operation temp range | -30~85℃ |
| Surrounding environment |
Humidity:-10~55℃ Storage:-25~65℃ Humidity:35~85%RH Storage:35~85%RH |
| Sampling frequency | ≥5KHZ |
| IP Class | IP64 |
3. Dimension
4. Application
24-Bit IP64 ≥5KHZ 10,40,640,1280 Times/Sec Load Cell Amplifier FA01A-A4 could be used for weight values displaying.
5.FAQ
Q1: What is your terms of delivery?
A: EXW, FOB, CFR and CIF.
Q2: Can you produce according to the samples?
A: Yes, we can produce according to your samples or technical drawings.
Q3:What is your sample policy?
A: We can supply the sample with discount if we have ready parts in stock, and customers pay the courier cost.
Q4: What's your quality guarantee policy?
A: Quality guarantee: 12 months.
If the product has quality problem within 12 months, please return it to us, we will repair it, if we can't repair it successfully, we will give you a new one; but the man-made damage, improper operation and force majeure will be excepted.
And you will pay the shipping cost of returning to us, we will pay the shipping cost of delivering to you.
