Product Details:
|
| Product Name: | Six Axis Force Sensor | Capacity: | Fx,Fy,Fz=50N; Mx,My,Mz=2Nm |
|---|---|---|---|
| Weight: | 0.06kg | Material: | Hard Aluminum Alloy |
| Protection Level: | IP64 | Precision: | 0.1%F.S. |
| High Light: | 50n six axis force torque sensor,2nm six axis force torque sensor,ip64 strain gauge load cell |
||
Fx Fy Fz Each 50N Mx My Mz Each 2Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor
1. Descriptions
Fx Fy Fz Each 50N Mx My Mz Each 2Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS46A is a model of FARS46 which belongs to our brand FIBOS FARS-Series. FARS46A can measure six-axis load Fx,Fy and Fz are 50N, Mx,My and Mz are the same 2Nm, its Diameter is 46mm and Height is 19.4mm, its weight is 0.06kg.
2. Specifications
| Product name | Six Axis Force Sensor | ||
| Model |
FARS46A
|
||
|
Fx,Fy [N]
|
50 | ||
|
Fz [N]
|
50 | ||
|
Mx,My [Nm]
|
2 | ||
|
Mz [Nm]
|
2 | ||
|
Diameter [mm]
|
46 | ||
|
Height [mm]
|
19.4 | ||
|
Material
|
Hard aluminum alloy | ||
|
overload level [%F.S.]
|
300
|
||
|
Precision [%F.S.]
|
0.1
|
||
|
Accuracy [%F.S.]
|
0.5
|
||
|
Weight [kg]
|
0.06 | ||
|
Supply voltage [VDC]
|
9-24
|
||
|
working temperature [°C]
|
0-80
|
||
|
Sampling Resolution [Bit]
|
24
|
||
|
Sampling frequency [Hz]
|
1000
|
||
|
Protection level
|
IP64
|
||
|
Communication method
|
RS422/RS485/MODBUS/CAN/EtherCAT/EtherNET/USB/Analog
|
||
|
*Some of the parameters are supporting data acquisition equipment parameters.
|
|||
3. Dimension
4. Application
Fx Fy Fz Each 50N Mx My Mz Each 2Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS46A could be used for vehicle dynamics studies in the automotive industry.
